E-5
Muting Q
The volume is muted temporarily when pressing the MUTE
button on the remote control. Press again to restore the volume.
X-Bass control Q
When the power is fi rst turned on, the unit will enter the
extra bass mode which emphasizes the bass frequencies,
and “X-BASS” will appear. To cancel the extra bass mode,
press the X-BASS button on the remote control.
Bass control Q
Press the BASS/TREBLE button to select “BASS”.1
Within 5 seconds, press the VOLUME (+ or -) button 2
to adjust the bass.
Treble control Q
Press the BASS/TREBLE button to select “TREBLE”.1
Within 5 seconds, press the VOLUME (+ or -) button to 2
adjust the treble.
Equalizer Q
When the EQUALIZER
MODE button is pressed,
the current mode setting will
be displayed. To change to
a different mode, press the
EQUALIZER MODE button
repeatedly until the desired
sound mode appears.
POPS
VOCAL
JAZZ
FLAT
GAME
CLASSIC
Equalizer off.
For game.
For classical music.
For pop music.
Vocals are enhance
d
For jazz.
Function Q
When the FUNCTION button on main unit is pressed, the
current function will change to different mode. Press the
FUNCTION button repeatedly to select desired function.
FM STEREOCD FM MONO AM
AUDIO IN
iPod USB
Note:
The backup function will protect the memorized function
mode for a few hours should there be a power failure or
the AC power cord becomes disconnected.
Volume auto fade-in Q
If you turn off and on the main unit with the volume set to
27 or higher, the volume starts at 16 and fades in to the
last set level.
Auto power on function Q
When you press any of the following buttons, the unit turns on.
iPod O
®
/ iPhone, CD, USB, AUDIO IN, TUNER (BAND)
on the remote control: Selected function is activated.
O button on the main unit: The unit turns on and
playback of the last function will start (CD, TUNER,
USB, iPod, AUDIO IN).
Auto power off function Q
The main unit will enter the stand-by mode (when iPod/
iPhone is not docked) after 15 minutes of inactivity during:
iPod/iPhone: No connection.
AUDIO IN: No detection of input signal or very low sound
audibility.
TUNER: No reception of broadcast signal.
CD / USB: In the stop mode.
Note:
However, if iPod/iPhone is docked, the unit will begin charging.
“CHARGE MODE” will be displayed.
General control
To turn the power on Q
The fi rst time the unit is plugged in, the unit will enter the
demonstration mode.
Function Main unit
Remote
control
Operation
Power on/
off
Press to turn the
power on or to
go to stand-by
mode.
Demo on/
off
____
Press to enter to
demonstration on
or off mode.
Display brightness control Q
To dim the display brightness, press the DEMO/DIMMER
button on the remote control.
Notes concerning use:
Replace the batteries if the operating distance is O
reduced or if the operation becomes erratic.
Periodically clean the transmitter on the remote control O
and the sensor on the unit with a soft cloth.
Exposing the sensor on the unit to strong light may O
interfere with operation. Change the lighting or the
direction of the unit.
Keep the remote control away from moisture, heat, O
shock, and vibrations.
Remote control (continued)
Volume control Q
Turn the volume knob toward VOL +/- (on main unit) or
press VOLUME +/- (on remote control) to increase or
decrease the volume.
