116 Chapter 5
Analog Measurements - Screens and Control Fields
AC Level Measurement AM Depth Measurement
Analog Measurements
AC Level Measurement
The type of measurement shown is dependent on the AF Anl In
settings. AC Level is displayed when the AF Anl In field is set to SSB
Demod, Audio In, Ext Mod, or Audio Out.
The AC Level measurement field displays either rms potential
(voltage) or audio power (Watts or dBm).
See "Displaying AF Measurements" on page 37, or the
"AF Anl In" field on page 123 for more information.
Screens on which this field is displayed
AF ANALYZER
RF ANALYZER
RF GENERATOR
AM Depth Measurement
This measurement field displays the percent depth of modulation of the
AM signal. This measurement is displayed when the AF Anl In field is
set to AM MOD or AM DEMOD.
See "Displaying AF Measurements" on page 37, or the
"AF Anl In" field on page 123 for more information.
Screens on which this field is displayed
AF ANALYZER
RF ANALYZER
RF GENERATOR
