Chapter 6 169
Configuration - Screens and Control Fields
Frame Clock Output (Gen)-(Anl) (User Defined)
Frame Clock Output
This field selects the frame clock signal to send to the FRAME CLOCK
OUT connector.
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
(Gen)-(Anl)
This field is used with the RF Offset field to specify the amount of
frequency offset between the RF generator and RF analyzer.
This field is always displayed when the RF Display field is set to
Freq
.
See "Setting an RF Generator/Analyzer Offset" on page 47 for more
information.
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
(Gen)-(Anl) (User Defined)
This field defines the receiver-transmitter frequency offset when using
user-defined channel operation.
Use a positive value (such as 45 MHz) when the radio’s receive
frequency is higher than the transmit frequency.
Use a negative value (such as −45 MHz) when the radio’s receive
frequency is lower than the transmit frequency.
Operating Considerations
The value of this field is only used if the RF Display field is set to
Chan, and the RF Chan Std field is set to USER-DEF.
For more information see the following related topics:
"Chan Space (User Defined)" field on page 164
"RF Chan Std" field on page 175
"RF Display" field on page 176
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
