176 Chapter 6
Configuration - Screens and Control Fields
RF Display RF Gen Volts
RF Display
This field selects the format for entering the RF generator’s and RF
analyzer’s frequencies:
• When Freq
is selected, you enter the RF generator’s and the RF
analyzer’s frequencies directly using the keypad or knob.
• When Chan
is selected, the RF Gen Freq and Tune Freq fields on
all screens are replaced by the RF Channel field, and only the
channel number is entered and displayed.
Channel tuning eliminates the need to enter transmit and receive
frequencies directly into the Test Set. Once your radio’s RF channel
standard is selected, you only have to enter the channel number to
automatically set the RF generator and RF analyzer to the correct
frequencies.
Operating Considerations
See the "RF Chan Std" field on page 175 for more information.
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
RF Gen Volts
This field specifies whether you want RF voltages expressed as the
voltage across a 50 ohm load, or the open circuit voltage (emf).
Operating Considerations
This setting affects the RF generator’s and the tracking generator’s
amplitudes.
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
