178 Chapter 6
Configuration - Screens and Control Fields
RF Level Offset RF Offset
RF Level Offset
This field enables/disables the RF level offsets entered in the RF
In/Out, Duplex Out, and Antenna In fields below it.
• When set to On
, the RF generator’s amplitude and RF analyzer’s
power measurement are offset by the values entered in these fields.
• When set to Off
, the values in these fields are ignored.
For more information see the following related topics:
"Antenna In" field on page 162
"Duplex Out" field on page 166
"RF In/Out" field on page 177
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
RF Offset
This field is displayed when the RF Display field is set to Freq.
This field enables/disables the RF generator−RF analyzer frequency
offset specified in the (Gen)-(Anl) field below it.
Operating Considerations
When an RF offset is used, changing the RF generator’s frequency or
RF analyzer’s tune frequency automatically alters the other setting.
See "Setting an RF Generator/Analyzer Offset" on page 47 for more
information.
Screen(s) Where Field is Present
INSTRUMENT CONFIGURE
