190
Connectors
FRAME CLOCK OUT HP-IB
FRAME CLOCK OUT
This output provides an external connection to several internal clocks.
The clocks are selected using the Frame Clock Output field on the
INSTRUMENT CONFIGURE screen. The frame clock selections are as
follows:
• 20.00 ms
• 26.67 ms
• 80.00 ms
• 2.00 s
HP-IB
This connector is optional on the Test Set.
This connector allows communication between the Test Set and other
instruments or computers using the Hewlett-Packard Interface Bus
(HP-IB).
For more information see the "HP-IB Adrs" field on page 170.
