192
Connectors
RF IN/OUT SCOPE MONITOR OUTPUT
RF IN/OUT
This Type-N connection is used to output signals from the RF generator
and to input RF signals.
CAUTION Overpower Damage — Refer to the Test Set’s connector
panel for maximum input power level. Exceeding this level
can cause permanent instrument damage.
If the RF power at the RF IN/OUT port exceeds allowable
limits, a loud warning signal sounds and a message
appears at the top of the screen. If this occurs, disconnect
the RF power, reset using
Meas Reset (press and release the
Shift key, then the Hold key), and allow the Test Set to cool
off for approximately 2 minutes before making any other
measurements on this port.
Operating Considerations
This port must be used when measuring TX (RF) power.
Signals ≤60 mW can be input to the ANT IN connector for all RF
measurements except TX Power.
This port can be selected on the RF ANALYZER, or SPEC ANL screens.
SCOPE MONITOR OUTPUT
This connector provides an external output from the AF analyzer.
Operating Considerations
The Scope To field in the AF ANALYZER screen determines the
source of this signal. For more information see the "Scope To" field on
page 149.
The level is not affected by the front-panel VOLUME knob.
