42 Chapter 2
Operating Overview
Changing the Increment or Decrement Setting
Changing the Increment or Decrement Setting
Specifying An Increment Value for the Arrow Keys or Knob
The Incr Set key is used to assign a specific increment value. The
increment value may use different units than the field you are
incrementing/decrementing. For instance; if the RF generator’s
Amplitude setting is displayed in dBµV, you could increment in units
of dB or mV.
To change the increment/decrement value
Step 1. Move the cursor to the numeric entry field to be changed.
Step 2. Press
Incr Set, and enter the desired incremental value and
unit-of-measure using the DATA ENTRY keys.
Step 3. Use the down-arrow and up-arrow keys or cursor
control knob to increment the field’s value. The field’s value
changes by the value you set for each key press or knob click.
Using the Factor of 10 Increment/Decrement Keys
The Incr × 10 and Incr ÷ 10 keys change the increment/decrement value by a
factor of 10.
For example, if you set the increment for Tune Freq to 10 MHz for
every click of the knob or push of the down-arrow or up-arrow keys,
pushing
Incr ×10 changes the increment value to 100 MHz.
