56 Chapter 3
Overview of the Test Set’s Built-In Tools
Using RF Tools Program
Using RF Tools Program
The RF Tools Program resides in the Test Set’s ROM. The following
tests and utility programs are available in this program.
See Figure 3-1 on page 57 for instructions on loading the RFTOOLS
program.
To run the tests or utilities in the RFTOOLS program:
1. Choose the test or utility you want to run from the list of choices.
2. Fill in the parameters that are displayed for each test.
The following tests and utility programs are available in this program.
• "Swept Gain" on page 58
• "Discrete Freq Insertion Loss" on page 59
• "Swept Insertion Loss" on page 59
• "Swept Return Loss" on page 60
• "Cable Fault" on page 62
• "Replot Data Files" on page 65
• "Transfer Stored Data" on page 65
• "SA (spectrum analyzer) Self Calibration ON/OFF" on page 65
• "Catalog PC (Memory) Card" on page 66
• "Set Up Printer/Data Collection" on page 66
