CABINET DIMENSIONS
–
Cabinet
Dimensions (inches)
Model Length Width Height Ship
DCSG/DCCG Outside Inside Outside * Inside Outside Wt.
-4 25 3/8 21 25 13/16 21 ½ 51 ¼
260
-8 47 7/16 43 1/8 25 13/16 21 1/2 51 1/4 405
-12 67 5/16 63 25 13/16 21 1/2 51 1/4 515
-16 87 7/16 83 1/8 25 13/16 21 1/2 51 1/4 625
* -D models (with doors) outside width = 27 9/16
CABINET CAPACITIES
–
Cabinet
Model Cu. Capacity (9 1/2 dia. 3 gal cans) # of lids
DCSG/DCCG Ft. Upper Display Lower Display
-4 3.3 4 - 1
-8 8.9 8 4 1
-12 14.5 12 8 2
-16 20.2 16 12 2
(Capacities of D models are the same as models without doors)
ELECTRICAL DATA
Cabinet Compressor Cabinet *
Model Volts HP L.R. F.L. Nominal Fuse
DCSG/DCCG Amps Amps Run Amps Amps
-4 115 1/3 33.0 6.4 6.9 15
-8 115 1/2 58.0 8.6 9.5 15
-12 115 1/2 45.0 7.8 9.9 15
-16 115 3/4 59.8 10.2 10.5 15
(electrical data of D models are the same as standard models)
* Includes main top heaters and
condenser
fan motors
Due to compressor change from semi-hermetic to hermetic these are the value changes
-8 (*hermetic)
115
½
51.0
.9
8.4
15
-12 (*hermetic) 115 ½ 87.0 7.9 12.0 15
*
effective
Aug.
2002
the
DCCG/DCSG-8
compressor
changed
from
a
semi-hermetic
HA TB-005E-IAA to her metic T2 155GK .
*
effective
Nov.
2003
the
DCCG/DCSG-12
compressor
changed
from
a
semi-hermetic
KAGB-0050-IAA to hermetic J2212GK Aspera
4
