Lenmar Enterprises BCGS324K/W Cell Phone Accessories User Manual



Model: BCGS324K/W
Pulsar - Samsung Galaxy S III Power Case
PLEASE READ THIS INFORMATION THOROUGHLY BEFORE USING THIS PRODUCT. IT CONTAINS IMPORTANT
OPERATING INSTRUCTIONS FOR YOUR UNIT.
Owner’s manual
Thank you for purchasing the Pulsar. The Pulsar case oers the convenience of an external battery built
into the full protection of a hard case. You can use it as a case all the time and enjoy the convenience of
extra battery power when you need it.
Included in the package you have purchased:
Pulsar, USB charging / sync cable and user manual
Note: Prior to initial use, fully charge your Pulsar before
connecting to your Samsung Galaxy S III.
You can charge the Pulsar case with the Micro USB to USB
cable included with the case. Just plug the Micro USB into
the case, and the other USB end into a computer USB port or
into a wall plug style adapter that has a USB output.
The LED status indicator shows the current charging status
of the case. The case charges, from right to left, the 1st LED,
2nd LED, 3rd LED and nally the 4th LED. Once the 4th LED
has become steady, the charging process has nished.
Battery Consumption
Your Pulsar will always drain rst until its power is 5%, and then your
Samsung Galaxy S III switches to its main battery.
With the Samsung Galaxy S III facing you, align your phone
micro-USB jack just above the micro USB tip in the Pulsar.
Gently slide down until the top of the phone sets itself
into the case.
Just plug the Micro USB into the Pulsar, and the other
USB end into a computer USB port or into a wall plug
style adapter that has a USB output.
With the Pulsar connected to the Samsung Galaxy S III
charging is as follows. First the Samsung Galaxy S III will
be charged fully and then the Pulsar begins to charge.
With the built in “ON / OFF” button you have the option of using the Pulsar when
you need it. When you need an extra charge in your phone, just push the button
and hold for two seconds to turn “ON” and the Pulsar case will proceed to charge
your main battery. When you are ready to turn it “OFF,” just hold the button again
for two seconds and the Pulsar will shut “OFF.”
Charging your Pulsar
Installing your Samsung Galaxy S III into the Pulsar
Charging your Pulsar with the Samsung Galaxy S III
On/Off Button
The integrated LED status indicator tells you exactly how much battery power is
left in your case. Simply press the “ON / OFF” button. The 1st LED will indicate
25% or less charge remaining, the 2nd LED will indicate between 25 – 50%
charge remaining and the 3rd LED will indicate 50 -75% charge remaining, and
the 4th LED will indicate 75-100% charge remaining.
Checking remaining capacity of the case
Using the supplied cable enjoy the convenience of charging and syncing your
Samsung Galaxy S III without ever removing the case. Just plug the Micro USB
cable into the case and the other end into your computer’s USB slot.
SYNC
Specifications
Cell type:
Input:
Output:
Capacity:
Dimensions:
Weight:
Compatibility:
Lithium-Polymer Battery
DC 5V500mA
DC 5V500mA
2400mAh / 8.9Wh
L152 x W70.4 x T14.6mm
90g
Samsung Galaxy S III
Standby:
Talk Time:
Internet Use:
Audio Play:
Video Play:
Up to 230 hours*
Up to 7.6 hours and on the 3G network.
Up to 8.8 hours on the 2G network.
Up to 7.6 hours and on the 3G network.
Up to 7 hours on Wi-Fi.
Up to 31 hours*
Up to 8.8 hours*
*All above times can vary due to device settings, location, and signal strength.
313-054-07-0617 r1.1 y1
Lithium-Polymer battery must be
recycled or disposed of properly.
LED Indicators
On/Off Button
Limited 1 Year Warranty
Lenmar product is warranted to be free of defective parts and workmanship for stated period from the original
date of purchase when sold through our website or our authorized retailers. Warranties are not transferable. The
warranty excludes damage resulting from accident, misuse, modication, delay or loss of use, damage to
equipment or by normal wear and tear.
ALL WARRANTY CLAIMS ARE PROCESSED ONLINE AT THE FOLLOWING LINK:
WWW.LENMAR.COM/WARRANTY
Warranty claims made after 60 days from the original date of purchase, will require a processing fee. Details will
be included while completing the online warranty request. Payment can be made via credit card when
completing the warranty form or a check can be included with the package when it is returned to Lenmar. Once
the request is completed, you will be emailed with a conrmation WRA number and instructions on how to
return the item for a warranty replacement.
Proposition 65 Notice (California)
The following statement is required in the state of California pursuant to the settlement of an action brought
by the Mateel Environmental Justice Foundation against multiple electronics and appliance manufacturers
• WARNING: Handling the cord on this product will expose you to lead, a chemical known to the
state of California to cause birth defects or other reproductive harm. Wash hands after handling.
For additional questions, comments, or to explore other Lenmar power solutions,
visit our website at: www.lenmar.com or call 800.424.2703 from 9AM – 5PM PST.
USB
USB
USB
Micro-USB Charging Jack
Micro-USB Charging Jack
1234
