Lenmar Enterprises PPUGOLD Cell Phone Accessories User Manual



Model: PPUGOLD
PowerPort™ Gold - All-in-One Charger
PLEASE READ THIS INFORMATION THOROUGHLY BEFORE USING THIS PRODUCT. IT CONTAINS IMPORTANT
OPERATING INSTRUCTIONS FOR YOUR UNIT.
Owner’s manual
Thank you for purchasing the PowerPort Gold, All-in-One Charger. Take the compact, lightweight PowerPort
Gold with you wherever you go and have the convenience of a portable battery as well as the ability to
recharge it while you’re at home or in the car.
The PowerPort Gold charges your PDA, smartphone, MP3 player, game system, or almost any device that can
be charged via a USB cable connection.
LED Power Indicator
With 3 built-in LED Power Indicators , you have the option of checking the
power level in the PowerPort Gold with the press of a button .
One LED indicates up to 25% power remaining.
Two LED’s indicate 50% power remaining.
Three LED’s indicate 75% - 100% power remaining.
Connecting the PowerPort Gold to your Device
PowerPort Gold & User Manual
Limited 1 Year Warranty
Lenmar product is warranted to be free of defective parts and workmanship for stated period from the original
date of purchase when sold through our website or our authorized retailers. Warranties are not transferable. The
warranty excludes damage resulting from accident, misuse, modication, delay or loss of use, damage to
equipment or by normal wear and tear.
ALL WARRANTY CLAIMS ARE PROCESSED ONLINE AT THE FOLLOWING LINK:
WWW.LENMAR.COM/WARRANTY
Warranty claims made after 60 days from the original date of purchase, will require a processing fee. Details will
be included while completing the online warranty request. Payment can be made via credit card when
completing the warranty form or a check can be included with the package when it is returned to Lenmar. Once
the request is completed, you will be emailed with a conrmation WRA number and instructions on how to
return the item for a warranty replacement.
Proposition 65 Notice (California)
The following statement is required in the state of California pursuant to the settlement of an action brought
by the Mateel Environmental Justice Foundation against multiple electronics and appliance manufacturers
• WARNING: Handling the cord on this product will expose you to lead, a chemical known to the
state of California to cause birth defects or other reproductive harm. Wash hands after handling.
For additional questions, comments, or to explore other Lenmar power solutions,
visit our website at: www.lenmar.com or call 800/424-2703 from 9AM – 5PM PST.
Included in the package you have purchased:
Do not overcharge the PowerPort Gold, as it will shorten its life span.
Disconnect the PowerPort Gold as soon as it is practical after the charge is complete. When not in use, unplug
the PowerPort Gold from all cables and devices. Do not drop.
Recycle or dispose of the PowerPort Gold properly. If disposed of in re or short circuited, the PowerPort may
leak or explode, causing personal injury.
Note:
The PowerPort Gold must be charged prior to rst use and may become warm during charging and use.
Note:
When charging the PowerPort Gold, the unit’s top LED light, called the
Charging Status Indicator , will light up red. When the charging process
is complete, the LED will turn green, indicating a full charge.
Chemistry: Lithium-Ion
AC Input: 100-240 VAC, 50/60Hz
AC Output : 5V, 1000 mA
DC Input 10.8 – 18 VDC
DC Output DC 5V, 1000 mA
Battery Capacity: 1500mAh
Dimensions: 90.1 x 60.5 x 27mm
Weight: 117g
Caution:
Specifications
312-080-42-0307 r2 y1
Lithium-Ion battery must be
recycled or disposed of properly.
Charge the PowerPort Gold at home by folding out the AC prongs and
installing it in a wall outlet.
Charge the PowerPort Gold in your vehicle by folding out the cigarette
lighter adapter and pluging it into your car’s DC port.
Attach your device using its USB charge/sync cable (not included) to
the PowerPort Gold USB port . Charging will start automatically,
to stop the charging process simply unplug your device from the
PowerPort Gold.
You may charge your device in the PowerPort Gold while the Gold is
connected to a wall outlet, car outlet, or use it as a portable battery
when it is not connected to a power source.
6
5
4
3
4
90 Foldable Cigarette Lighter Adapter
90 Foldable AC Prong
Power Status Button
Charging Status Indicator
LED Power Indicator
2
3
4
5
Charging your PowerPort Gold
USB
3
5
5
6
6
4
USB Output Port
6
2
2
3
1
2
