Charge the battery
1. Connect a
compatible
charger to a
wall outlet.
2. Connect the
power cord to
the device. If
the battery is
completely
discharged, it
may take a while before the charging indicator
starts scrolling.
3. When the battery is fully charged, the charging
indicator stops scrolling. Disconnect the charger
from the device, then from the wall outlet.
Tip: Disconnect the charger from the wall
outlet when the charger is not in use. A
charger that is connected to the outlet
consumes power even when it is not
connected to the device.
Attach wrist strap
1. Remove the back cover.
2. Thread a wrist strap, and tighten it.
3. Replace the cover.
Antenna locations
Your device may have internal and external
antennas. As with any radio transmitting device,
avoid touching the antenna area unnecessarily
while the antenna is transmitting or receiving.
Contact with such an antenna affects the
communication quality and may cause the device to
operate at a higher power level than otherwise
needed and may reduce the battery life.
1 — Cellular antenna
2 — FM transmitter antenna
3 — Bluetooth and wireless LAN antenna, and GPS
receiver
17
Get started
