42 GS170 | User Guide
Installing the SIM Card
When you start your cellular service, you are provided with a SIM
card that is loaded with your subscription details, any optional
services available, and many other features.
Important! : The SIM card and its contents can be easily damaged
by scratches or bending, so be careful when handling,
inserting, or removing the card. Keep all SIM cards out
of the reach of small children.
SIM Card Instructions:
1 Slide the battery cover downwards and lift it away from the
phone.
2 Lift the battery up and out to remove it.
3 Carefully slide the SIM card into the SIM card slot. Make sure
that the card’s gold contacts are facing downwards.
4 Align the battery’s gold contacts with the gold contacts on the
phone’s battery compartment and press down on the battery
until it snaps into place.
5 Replace the battery cover by lining up the cover (as shown
in the corresponding illustration below) and then sliding it
upwards until it snaps into place.
6 To charge the battery, unfasten the Headset/Charger port
cover on the right side of the pone and plug in the power
adapter’s connector into it. Make sure that side ‘B’ of the small
end of the adapter facing upwards. Plug in the adapter into a
standard AC wall outlet.
1
5
2
4
6
3
WARNING: Do not remove the battery when the phone is
switched on, as this may damage the phone.
M
Installing the SIM Card and Charging the Battery
