4. HIGHSPEED AT-COMMANDS
On the table below it is described AT-commands for Modem, ISDN v.110 and ISDN v.120
connections with different channel coding (speed of each slot) and timeslots (number of
receiving/transmitting slots). For example 3+1, 28800, 9600 means that the maximum speed
that you can receive data is 3x9600=28800 and maximum speed for sending data is
1x9600=9600, the maximum connection speed that is shown in the task tray is the same as
the maximum sending speed (28800).
Modem
at+cbst=7,0,1;+chsn=1,1,0,4
Timeslots Max Connection Speed Ch. Coding Protocol
1+1 9600 9600 V.32
at+cbst=12,0,1;+chsn=1,1,0,4
Timeslots Max Connection Speed Ch. Coding Protocol
1+1 9600 9600 V.34
at+cbst=14,0,1;+chsn=2,1,0,8
Timeslots Max Connection Speed Ch. Coding Protocol
1+1 14400 14400 V.34
at+cbst=15,0,1;+chsn=3,2,0,4
Timeslots Max Connection Speed Ch. Coding Protocol
2+2 19200 9600 V.34
at+cbst=16,0,1;+chsn=4,3,0,4
Timeslots Max Connection Speed Ch. Coding Protocol
3+1 28800 9600 V.34
at+cbst=16,0,1;+chsn=4,2,0,8
Timeslots Max Connection Speed Ch. Coding Protocol
2+2 28800 14400 V.34
V.110
at+cbst=71,0,1;+chsn=1,1,0,4
Timeslots Max Connection Speed Ch. Coding Protocol
1+1 9600 9600 V.110
at+cbst=75,0,1;+chsn=2,1,0,8
Timeslots Max Connection Speed Ch. Coding Protocol
1+1 14400 14400 V.110
4/6
