2 Screen
3 Call key
4 Microphone
5 Charger connector
6 Micro-USB connector
7 Headset connector (Nokia AV connector 3.5 mm)
8 Volume up/Zoom in key
9 Volume down/Zoom out key
10 Lock key
11 End/Power key
12 Camera lens. Before using the camera, remove the protective tape from the lens.
13 SIM card slot (SIM 2)
14 Memory card slot
15 Loudspeaker
Insert a primary SIM card and battery
Note: Switch the device off and disconnect the charger and any other device before
removing any covers. Avoid touching electronic components while changing any
covers. Always store and use the device with any covers attached.
Important: This device is designed to be used with a standard SIM card (see figure)
only. Use of incompatible SIM cards may damage the card or the device, and may
corrupt data stored on the card. Please consult your mobile operator for the use of
a SIM card that has a mini-UICC cutout.
Important: To prevent damage to the SIM card, always remove the battery before
you insert or remove the card.
This phone is intended for use with a BL-4U battery. Always use original Nokia
batteries.
6 Get started
