Specifications
Bands Supported......................................................GSM 900 Class 4
GSM1800 Class 1
GSM1900 Class 1
Standby Time* ..........................................................90 to 300 hours
Talk Time*.................................................................3 to 12 hours
Temperature Range
Charging.........................................................+5°C ~ +35°C
Storage...........................................................-20°C ~ +60°C
Weight (A100)...........................................................66 g (including battery)
Weight (A101)...........................................................69 g (including battery)
Weight (A102)...........................................................68 g (including battery)
Dimensions (A100)
Height .............................................................77 mm
Width...............................................................44 mm
Depth..............................................................17.8 mm
Dimensions (A101)
Height .............................................................80 mm
Width...............................................................44 mm
Depth..............................................................19 mm
Dimensions (A102)
Height .............................................................77 mm
Width...............................................................44 mm
Depth..............................................................18 mm
Volume............................................................55 cc
Supply Voltage..........................................................3.7 V (780 mAh Li-ion)
Antenna.....................................................................Fixed
Charge Time** ..........................................................Up to 150 min
SIM Type...................................................................3 V only
Contacts Memory......................................................250 entries + SIM
Animation Themes....................................................2
User Composed Melodies.........................................5
Games ......................................................................2
Backlight Colour........................................................Blue
Ring Tones................................................................Preset: 15
Composed: 5
Scheduler..................................................................Up to 50 entries
Alarm.........................................................................1
Maximum Graphics Size...........................................Main: W112 x H64 pixels
(monochrome)
NOTE: Specifications are subject to change without notice.
*Talk and Standby times depend on network conditions, SIM usage and battery
condition.
**Charging time depends on usage and condition.
