Initializing the NJ205 IntelliJack
23
5 Enter Location Information for the particular NJ205 you are
configuring. This field can help you and other network
managers identify this IntelliJack in the future. You may
enter any information you like (up to 256 characters), but
we recommend that you enter a logical, easy to follow
description, such as “Building A, 3rd floor, room 315, West
wall.”
6 Enter a Group Name for this IntelliJack. This can be any
name you wish. With the Central Configuration Manager,
you can perform management tasks on all IntelliJacks with
the same group designation.
7 Select the method the NJ205 should use to obtain an IP
address. The NJ205 can either get an IP address from an
existing DHCP server on your network or you can directly
specify the address. If you elect to specify your own
address, you should enter the IP Address, Subnet Mask, and
Default Gateway information in the appropriate fields.
NOTE: By default, the NJ205 is configured to
automatically obtain an IP address from a DHCP
server. If no DHCP server exists, or if the NJ205
cannot obtain an IP address, it will default to
the IP address 192.168.1.252.
