28 Chapter 1
Super I/O controller NS PC87393
MODEM South bridge/VIA VT8235
Blue tooth South bridge/VIA VT8235
Wireless 802.11g BCM4306KFB
PCMCIA TI PCI1410
Audio RealTek ALC202
Four-in-one card reader M220V0315
Touchpad Synaptics TM41P-353
IR Vishay TFU6102F
Keyboard
Item Specification
Keyboard controller NS 87570 C4
Keyboard vendor & model name DARFON
Total number of keypads 84/85 key
Windows logo key Yes
Internal & external keyboard work
simultaneously
No
Note: Internal and external keyboard can not work
simultaneously by software specification.
Battery
Item Specification
Vendor & model name Simplo/Sanyo
Battery Type Li-ion
Pack capacity 4400 Ah
Cell voltage 3.7V/cell
Number of battery cell 8
Package configuration 4 cells in series, 2 series in parallel
Package voltage 14.8V
LCD
Item
Vendor & model name AU B150XG01 HITACHI TX38D81VC LG LP150X08
Mechanical Specifications
LCD display area
(diagonal, inch)
15.0 15.0 15.0
Display technology TFT TFT TFT
Resolution XGA (1024x768) XGA (1024x768) XGA (1024x768)
Supports colors 262K 262K 262K
Optical Specification
Contrast ratio 300 100 175 (Min.) 250 (Typ.)
Response time(msec) Rising: 24 (Typ.) 15
(Max.)
Falling: 11 (Typ.) 30
(Max.)
Rising: 30 (Typ.) 50
(Max.)
Falling: 30 (Typ.) 50
(Max.)
Rising: 10 (Typ.) 20
(Max.)
Falling: 20 (Typ.) 30
(Max.)
System Board Major Chips
Item Controller
