System memory configuration guidelines
• To ensure data integrity, use only Acer-approved modules in 1 GB or 2 GB
capacities.
• Use identical modules — same specification for size, speed, and
organization.
• In minimum configuration, the FDB should be installed in DIMM 2 slot.
• Install memory pair upgrades in the following sequence:
• First pair: DIMM 2, DIMM 4 and DIMM 6
• Upgrade 1: DIMM 1, 3 and 5
• Upgrade 2: DIMM 1, 2, 3, 4, 5 and 6
• Observe the population sequence illustrated in the table below when
installing a memory module.
Channel A Channel B Channel C
DIMM 1 DIMM 2 DIMM 3 DIMM 4 DIMM 5 DIMM 6
1 GB
1 GB 1 GB
1 GB 1 GB 1 GB
1 GB 1 GB 1 GB 1 GB
1 GB 1 GB 1 GB 1 GB
1 GB 1 GB 1 GB 1 GB 1 GB
1 GB 1 GB 1 GB 1 GB 1 GB
1 GB 1 GB 1 GB 1 GB 1 GB 1 GB
2 GB
2 GB 2 GB
2 GB 2 GB 2 GB
2 GB 2 GB 2 GB 2 GB
2 GB 2 GB 2 GB 2 GB
2 GB 2 GB 2 GB 2 GB 2 GB
2 GB 2 GB 2 GB 2 GB 2 GB
2 GB 2 GB 2 GB 2 GB 2 GB 2 GB
