7.4 Connecting the EXP-06E to a host
The connector – G, H, I connects a single EXP-06E to the host computer via RS-232C
format. Multiple EXP-06E communicates with host from connector – F, E via RS-485
format. But the EXP-06E chain must communicate with host through an
RS232/RS-485 converter.
7.4.1 Configuring the EXP-06E Jumpers
Configure EXP-06E jumpers JP4 & JP5 for the host communication format you are
using. For host communication using the RS-232C communication using the RS-485
communication protocol, set jumpers JP4 & JP5 to 1-2 position.
7.4.2 RS-232C Connection
Table – Pin connection
EXP-06E Pin Signal DB25 DB9 Host Signal
I
Ground 7 5 Ground
H
Data Transmit 3 2 Data Receive
G
Data Receive 2 3 Data Transmit
7.4.3 Remote Modem Connection
Table – Pin connection (RS-232)
EXP-06E Pin Signal DB25 DB9 Host Signal
I
Ground 7 5 Ground
H
Data Transmit 2 3 Data Receive
G
Data Receive 3 2 Data Transmit
4&5 Sort 4&6 Sort
6&20 Sort 7&8 Sort
Table – Pin connection (RS-485)
Signal DB25 (485 Converter) DB9 (Modem) Host Signal
Ground 7 5 Ground
Data Transmit 3 3 Data Receive
Data Receive 2 2 Data Transmit
4&5 Sort 4&6 Sort
6&20 Sort 7&8 Sort
