1. Take two plastic drive rails and mount them to the sides of the 5.25” device.
Make sure to use the front set of the screw holes on the drive rail.
Also make sure the end of the drive rail is angled away from the device and
facing forward.
2. Slide the device into the drive bay until you hear a click.
3. Mount the other devices accordingly.
4. Find the appropriate power connector on the power supply and connect it to
the connector on the device.
To install a floppy or other external 3.5” device to the 5.25” to 3.5” Adapter:
1. Slide the Adapter out.
2. Place the drive to the adapter and fasten the drive with screws provided.
3. Find a 4-pin floppy power connector on the power supply and connect it to
the male 4-pin connector on the devices.
Cooling System
The TriCool™ fan:
The case includes one 120mm TriCool™ fan installed in the rear. This fan has a
three-speed switch that lets you choose between quiet, performance, or maximum
cooling. (See specifications below.) The fan is installed so that the air is blowing
out of the case. Connect a large 4-pin connector from the power supply to the
male 4-pin connector on the fan.
Note: The minimum voltage to start the fan is 5V. We recommend that our users
set the fan speed to High if you choose to connect the fan to a fan control device
or to the Fan-Only connector found on some of Antec’s power supplies. A fan-
control-device regulates the fan speed by varying the voltage to it. The voltage
may start as low as 4.5V to 5V. Connecting a TriCool™ set on Medium or Low
to a fan-control device may result in the fan not being able to start. The already
lowered voltage from the fan control device will be further reduced by the TriCool™
circuitry below 5V.
Specifications:
Size: 120mm x 120mm x 25.4mm
Rated Voltage: DC 12V
Operating Voltage: 10.2V ~ 13.8V
Speed Input
Current
Air Flow Static
Pressure
Acoustical
Noise
Input
Power
High
2000 RPM
0.24A
(Max.)
2.24 m³ / min
(79 CFM)
2.54 mm-H2O
(0.10 inch-H2O)
30 dBA 2.9 W
Medium
1600 RPM
0.2A 1.59 m³ / min
(56 CFM)
1.53 mm-H2O
(0.06 inch-H2O)
28 dBA 2.4 W
Low
1200 RPM
0.13A 1.1 m³ / min
(39 CFM)
0.92 mm-H2O
(0.04 inch-H2O)
25 dBA 1.6 W
