Secure DVI-I KVM Dual-Head Switch with Audio
OVERVIEW
SECTIONSTable of Contents 1 2 3 4 5 6 7 82
Unit Display Diagram, Front View
IMPORTANT
NOTICE:
If for any reason
the tamper-evident
seal is missing,
appears disrupted,
or looks different
than the example
shown here, please
call Belkin Technical
Support at (800)
282-2355.
Insert color chip Remove color chip
with a standard paperclip
Console
12V, 1.5A
Audio
Display
PS2 K PS2 MMouse Keyboard
CAC
4
K/M CACAudio
Video
3
K/M CACAudio
Video
2
K/M
CAC
Audio
Video
1
K/M CACAudio
Video
Tamper-Evident Seal
Name Label Guide
Port Selector
CAC Enable Switch
(F1DN104F model only)
Color Chip
LED Indicator
(F1DN104F model shown)
