1-3
Introduction
LANVIEW LEDs
The 9A426-02 Module uses LANVIEW – Cabletron Systems built-in visual
diagnostic and status monitoring system. With LANVIEW LEDs, you can quickly
identify the device, port, and physical layer status at a glance.
Figure 1-1. The 9A426-02 Module
SMB CPU
INB
ATM
9A426-02
FNB
A
T
M
1
A
T
M
2
For a complete list of supported MIBs, refer to the release notes provided in the
9A426-02 Module package.
NOTE
