ESX-1320/ESX-1380 Installation Guide v
CONTENTS
CHAPTER 1 INTRODUCTION
1.1 Using This Manual.......................................................................1-2
1.2 Features ......................................................................................1-2
1.3 Document Conventions ...............................................................1-5
1.4 Related Manuals.......................................................................... 1-5
1.5 Getting Help................................................................................. 1-6
CHAPTER 2 CONTROLS AND INDICATORS
2.1 LANVIEW LEDs........................................................................... 2-1
2.2 RESET Button .............................................................................2-1
2.3 LCD Display................................................................................. 2-2
2.4 Network Management Capabilities..............................................2-2
2.5 Simplex or Full Duplex Mode Operation......................................2-2
CHAPTER 3 INSTALLATION
3.1 Unpacking the ESX .....................................................................3-2
3.2 Removing the Chassis Cover......................................................3-3
3.3 Setting Mode Switches................................................................3-5
3.4 NVRAM Reset Switch.................................................................. 3-8
3.5 SIMM Upgrades........................................................................... 3-9
3.5.1 Locating SIMMs.............................................................. 3-9
3.5.2 Installing SIMMs .............................................................3-9
3.6 BRIM Connection ......................................................................3-12
3.7 Installing the ESX ......................................................................3-12
3.7.1 Tabletop or Shelf Installation ........................................ 3-13
3.7.2 Rackmount Installation .................................................3-14
3.7.3 Connecting to the Power Source.................................. 3-16
3.8 Pre-Network Installation Test ....................................................3-17
3.9 Connecting to the Network ........................................................3-19
3.9.1 Connecting a Twisted Pair Segment to the ESX-1320. 3-19
3.9.2 Connecting a 10BASE-F Segment to the ESX-1380.... 3-21
