High Speed Interface Configuration Menu Screen
2M46-04R/2M46-04RDC User’s Guide 5-43
The following briefly explains each screen accessible from the High
Speed Interface Configuration Menu screen:
FAST ETHERNET INTERFACES
Displays a screen named High Speed Interface Configuration which
shows the types of Fast Ethernet Interface Modules installed in ports 1
and 2, their current operating mode, and indicates if the ports are linked.
This screen also allows the user to enable or disable Auto-Negotiation and
set the Advertised Ability. For details, refer to Section 5.14.
HSIMS
Displays the types of interfaces installed in the High Speed Interface
Module (HSIM) slots. The HSIM screens are depicted in their respective
user’s guides.
