Chapter 7 Performing Switch Administration
How to Perform Switch Administration
Command Purpose
Step 1
configure terminal Enters global configuration mode.
Step 2
snmp-server host host-addr {traps | informs} {version {1
| 2c | 3}} community-string notification-type
Specifies the recipient of the trap message.
• host-addr—Specifies the name or address of the
NMS.
• traps (the default)—Sends SNMP traps to the
host.
• informs—Sends SNMP informs to the host.
• version—Specifies the SNMP version to
support. Version 1, the default, is not available
with informs.
• community-string—Specifies the string to send
with the notification operation. You can set this
string by using the snmp-server host command,
but we recommend that you define this string by
using the snmp-server community command
before using the snmp-server host command.
• notification-type—Uses the mac-notification
keyword.
Step 3
snmp-server enable traps mac-notification threshold Enables the switch to send MAC threshold
notification traps to the NMS.
Step 4
mac address-table notification threshold Enables the MAC address threshold notification
feature.
Step 5
mac address-table notification threshold [limit
percentage] | [interval time]
Enters the threshold value for the MAC address
threshold usage monitoring.
• (Optional) limit percentage—Specifies the
percentage of the MAC address table use; valid
values are from 1 to 100 percent. The default is
50 percent.
• (Optional) interval time—Specifies the time
between notifications; valid values are greater
than or equal to 120 seconds. The default is 120
seconds.
Step 6
end Returns to privileged EXEC mode.
