PowerTALK 101
23
either a network
connected or serially
connected PC.
Configuration storage Non-volatile memory on
board
Ditto
Firmware upgrade In Flash memory Ditto
Power supply voltage 230VAC, unless otherwise
specified
Ditto
Power supply current 0.2A typical at input of
230VAC
Ditto
Power supply output 20W, regulated 5V
0.6W, unregulated 12V
Ditto
Internal PSU fuse 1A 5mmx20mm fast blow Ditto
External fuse 3A 5mmx20mm slow blow Ditto
Enclosure All metal (steel) case, 19”,
4U, maximum depth of
340mm, including the
protruding terminals on the
back of the unit.
Ditto
Material of top & bottom plates 1mm mild steel, powder
coated
Ditto
Material of central part 2mm galvanised steel,
powder coated
Ditto
Material of front plate 0.9mm brushed stainless
steel
Ditto
Environmental 0 to 50 degrees C Ditto
