1 Manufacturer
Crown Equipment Corporation Crown Equipment Corporation
2 Model SP 3505-30 SP 3510-30
3 Load Capacity* lb See Chart See Chart
4 Load Center Platform face to load CG in 24 24
5 Power Electric Volts 24 24
6 Operator Type Stand-up Rider Stockpicker Stockpicker
7 Tire Type Load/Drive Poly/Poly Poly/Poly
8 Wheels (x = driven) Load/Drive 4/1x 4/1x
10 Lifting Height in See Chart See Chart
13 Head Length TL/TT in 74.6/75.6 74.6/75.6
14 Forks Standard L x W x T in 36 x 4 x 2 36 x 4 x 2
Optional Lengths in
30, 39, 42, 45, 48, 54, 60, 72, 84 30, 39, 42, 45, 48, 54, 60, 72, 84
15 Wheelbase TL/TT in 52/51 52/51
16 Turning Radius TL/TT in 69/68 69/68
20 Speed Travel Empty/Loaded mph See Chart See Chart
21 Speed Lift TL Empty/Loaded fpm 45/28 45/28
TT Empty/Loaded fpm 40/26 40/26
22 Speed Lower TL Empty/Loaded fpm 40/38 Low, 80/75 High 40/38 Low, 80/75 High
TT Empty/Loaded fpm 40/38 Low, 80/75 High 40/38 Low, 80/75 High
23 Battery Type Lead Acid Lead Acid
Min Weight/Max Amp 975/660 1520/1085
Max Battery Size 13.12 x 31.75 x 23.25 High 14.25 x 36.25 x 31 High
TL
10 Lifting Height in 136 148 172 194 214
3 Load Capacity SP 3505 lb 3000 3000 3000 3000 3000
SP 3510 lb 3000 3000 3000 3000 3000
SP 3520 lb 3000 3000 3000 3000 3000
SP 3550H lb na na na na na
Free Lift in 3 6 6 6 6
11 Collapsed Height in 89.5 95 107 119 131
12 Extended Height in 223 235 259 281 301
18 Straddle Width in 42 42 42 42 42
19 Operator Compartment Width in 42 42 42 42 42
17 Aisle Guide Wheel Range† in 45.50 to 65.25 45.50 to 65.25 45.50 to 65.25 45.50 to 65.25 45.50 to 65.25
Truck Weight SP 3505 lb 5027 5086 5216 5504 5634
Without Battery
SP 3510 lb 5027 5086 5216 5504 5634
SP 3520 lb 5088 5147 5277 5565 5695
SP 3550H lb na na na na na
General Information
Dimensions
Performance
* Contact factory. Capacity may be subject to derating, depending upon lifting height, load center and fork length.
Battery
Mast
† In .25" increments.
†† 48" straddle width on SP 3405 only.
Capacity
Truck Weight
