FORMULA™ QUICK REFERENCE GUIDE
4 EASYGEN™
4.1 SET UP THE TERMINAL FOR THE CONNECTION WITH THE PC
Insert the battery set into the terminal, close the cover, connect the power adapter to
the terminal and let it initially charge overnight. Then insure the charging LED light
displays a GREEN status (refer to Formula™ User’s manual for further details).
The Formula™ Terminal must first be REFLASHED via the following sequence:
Press and hold the POWER button, then press SCAN key. Press the DOWN arrow to
erase the program when prompted. Select option 3 (Serial). The Formula™ will
display the following information, indicating it is in receive mode via serial
communications:
BOOTSTRAP-
LOADER
WaitDownload Ser
Insert the terminal into the cradle and connect it to any standard 9-pin serial null-
modem cable (see Formula™ User’s manual for connection details).
4.2 INSTALLING AN EASYGEN™ EXAMPLE
To correctly download an EasyGen™ application open the SYSTOOLS software
program. There are two versions of this program: “STANDARD and ENHANCED”
mode and “EASYGEN” mode. Insure that EASYGEN mode is enabled by selected
Utility Menu – Set SysTools Mode.
Select Utility Menu – Send EasyGen Intepreter, browse and select the interpreter file
(EIFOR_XXX.H00).
Default path:
C:\Program Files\Datalogic\Formula Software Tools\EasyGen\Interpreters).
