The LAN icon will appear on the Taskbar indicating the LAN connection status.
By double tapping on the LAN icon in the
Taskbar, the LANNDS1 applet allows
visualizing the TCP/IP information. Other
information such as the MAC Address is
available by tapping the Details... button.
If it is necessary to set static TCP/IP
parameters, you must open the
LANNDS1 applet from the Network and
Dial-up Connections applet in the
Control Panel. This applet is only visible
when the mobile computer is correctl
inserted into the Ethernet Multi Cradle.
LAN icon
Ethernet LANNDS1 Communications Window
The IP Address belongs to Datalogic Jet™ while the MAC address is specific to each
cradle slot.
Windows Mobile Ethernet Cradle
Before using the ethernet cradle you have to un-check the 'COM1 Enable' option on
the 'System Configuration' window (Start -> Programs -> System Configuration) and
re-boot the unit.
For internet browsing through the ethernet cradle ensure that programs that
automatically connect to the internet should connect using 'My Work Network' -> go
to Start -> Settings -> Connections -> Connections -> Advanced -> Select Networks:
