l Setup Password — Allows you to restrict access to the System Setup program in the same way that you restrict access to your system with the system
password feature.
l System Password — Displays the current status of your system's password security feature and allows you to assign and verify a new system
password.
l Power Button — When this option is set to Enabled, you can use the power button to turn the system off or shut down the system if you are running
Microsoft®Windows®2000 or another operating system that is compliant with the ACPI specification. If the system is not running an ACPI-compliant
operating system, power is turned off immediately after the power button is pressed. When this option is set to Disabled, you cannot use the power
button to turn off the system.
l NMI Button — When this option is set to Enabled and the button is pressed, an NMI alerts the system. Use this button only if directed to do so by
qualified support personnel or by the operating system's documentation.
Console Redirection Screen
This screen is used to configure the console redirection feature:
l Console Redirection — Toggles the console redirection feature On (default) or Off.
l Remote Terminal Type — Allows you to select either VT 100/VT 220 (default) or ANSI.
l Redirection after Boot — Enables (default) or disables console redirection after your system restarts.
For more information on using console redirection, your User's Guide.
Exit Screen
After you press <Esc> to exit the System Setup program, the Exit screen displays the following options:
l Save Changes and Exit
l Discard Changes and Exit
l Return to Setup
Using the System Password Feature
Your system is shipped to you without the system password feature enabled. If system security is a concern, you should operate your system only with
system password protection.
You can assign a system password whenever you use the System Setup program. After a system password is assigned, only those who know the password
have full use of the system.
When the System Password option is set to Enabled, the system prompts you for the system password just after the system starts.
To change an existing system password, you must know the password (see "Deleting or Changing an Existing System Password"). If you assign and later
forget a system password, you must remove the system cover to change a jumper setting that disables the system password feature (see "Disabling a
Forgotten Password"). Note that this erases the setup password at the same time.
Assigning a System Password
Before you can assign a system password, you must enter the System Setup program and check the System Password option.
When a system password is assigned, the setting shown for the System Password option is Enabled. If the Password Status option is Unlocked, you can
change the system password. If the Password Status option is Locked, you cannot change the system password. When the system password feature is
disabled by a jumper setting on the system board, the setting shown is Disabled, and you cannot change or enter a new system password.
When no system password is assigned and the password jumper on the system board is in the enabled (default) position, the setting shown for the System
Password option is Not Enabled and the Password Status field is Unlocked. To assign a system password, perform the following steps:
1. Verify that the Password Status option is set to Unlocked.
2. Highlight the System Password option and then press <Enter>.
