Feature Description
Depth 46.30 mm (1.82 inches)
Weight 0.26 kg (0.57 lb)
Life span 300 discharge/charge cycle
Voltage
• 14.80 VDC (4 cells)
Temperature range:
Operating 0 °C to 35 °C (32 °F to 95 °F)
Non-Operating –40 °C to 65 °C (–40 °F to 149 °F)
Coin-cell battery 3 V CR2032 lithium ion
Table 14. AC Adapter
Feature Description
Type 65 W
Input voltage 100 VAC to 240 VAC
Input current (maximum) 1.50 A/1.60 A/1.70 A/2.50 A
Input frequency 50 Hz-60 Hz
Output power 65 W
Output current 3.34 A/4.62 A
Rated output voltage 19.50 VDC
Temperature range:
Operating 0 °C to 40 °C (32 °F to 104 °F)
Non-Operating –40 °C to 70 °C (–40 °F to 158 °F)
Table 15. Physical
Feature
Height 25.40 mm (1.00 inch)
Width 346.00 mm (13.62 inches)
Depth 246.00 mm (9.68 inches)
Weight (minimum) 2.01 kg (4.43 lb)
Table 16. Environmental
Feature Description
Temperature:
Operating 0 °C to 40 °C (32 °F to 104 °F)
Storage –40 °C to 65 °C (–40 °F to 149 °F)
