Discrete
NVIDIA Quadro NVS 3100M
Output
15-pin VGA connector
20-pin DisplayPort connector
Audio
Type
two-channel high-definition audio codec (HDA)
Controller
IDT 92HD81B
Speaker
two
Internal speaker amplifier
2 W channel
Volume controls
volume up, volume down, and mute buttons
Communications
Modem
internal (optional)
Network adapter
10/100/1000 Mbps Intel 82577LM Gigabit Ethernet
Controller
Wireless
dedicated WLAN, WWAN, WiMAX, and Bluetooth®
wireless support if optional cards are purchased.
GPS
mobile broadband mini-card
ExpressCard
NOTE: TheExpressCardslotdoesNOTsupportPCCards.
ExpressCard connector
ExpressCard slot
Cards supported
34 mm ExpressCards
PC Card
NOTE: ThePCcardslotdoesNOTsupportExpressCards.
PC card connector
PC Card slot
Cards supported
54 mm PC cards
Secure Digital (SD) Memory Card Reader
Cards supported
SD / MMC / SDHC / SDHS / MiniSD / MicroSD / SDIO
Contactless Smart Cards (Optional)
Supported Smart Cards and Technologies
ISO14443A — 106 kbps, 212 kbps, 424 kbps, and
848 kbps
ISO14443B — 106 kbps, 212 kbps, 424 kbps, and
848 kbps
ISO15693
HID iClass
FIPS201
NXP Desfire
Fingerprint Reader (Optional)
Type
swipe fingerprint sensor, FIPS 140-2 / FIPS 201
PortsandConnectors
Audio
microphone connector, stereo
headphone/ speakers connector
Video
one 15-pin VGA connector
one dual-mode DisplayPort connector
Network adapter
one RJ-45 connector
Modem
one RJ-11 connector
IEEE 1394
one 4-pin connector
USB
three USB 2.0-compliant connectors
one eSATA/USB 2.0-compliant connector
Memory card reader
one 6-in-1 memory card reader
Smart card reader
integrated smart card reader
Mini-Card
two half-height mini-card slots
one full-height mini-card slot
Docking connector
one E-Family 144–pin docking connector
Drives
Hard drive
SATA 2 HDD
SATA 2 Mobile HDD
