a. Align the notch in the module edge connector with the tab in the connector slot.
b. Slide the module firmly into the slot at a 45-degree angle.
c. Rotate the module down until it clicks into place. If you do not feel the click, remove the module repeat from Step 3a.
e. Replace the cover.
DIMM A Memory Module
DIMM A bay is located under the keyboard. Detaching the keyboard from the computer is not required to access the DIMM A memory module bay.
1. Remove the hinge cover (see Hinge Cover).
2. Remove the two M2.5 x 5-mm screws at the top of the keyboard.
3. Lift the keyboard only enough to lay it face down on the glidepad.
4. If you are replacing a memory module, remove the existing module:
5. Use your fingertips to carefully spread apart the securing clips on each end of the memory module connector until the module pops up.
6. Ground yourself and install the new memory module:
a. Align the notch in the module edge connector with the tab in the connector slot.
b. Slide the module firmly into the slot at a 45-degree angle.
c. Rotate the module down until it clicks into place. If you do not feel the click, remove the module repeat from Step 3a.
g. Return the keyboard to the normal position. Replace the two M2.5 x 5-mm screws located at the top of the keyboard.
8. Replace the hinge cover (see Hinge Cover).
Verify Memory Size
1. Insert the battery into the battery bay, or connect the AC adapter to your computer and an electrical outlet.
