D/Bay connects to the
D/Bay connector on the
left side of the system.
The connector is
comprised of a standard
USB 2.0 port plus an
additional power pin to
facilitate support for
external HDD and
writeable optical devices
D/Bay uses Dell
Latitude D Family
modules, which are
inserted and removed
via the front of the
D/Bay
D/Bay cable is
integrated into
the D/Bay
housing and is
non-removable
Dell D/Bay
Dell D/Bay External Modular Bay
• D/Bay is an option with the Latitude X300 system. However, an optical drive is required to be
ordered either via the D/Bay or the MediaBase. An 8X DVD drive is the standard upgradeable to
any other Latitude D Family optical device, external HDD, or FDD, or customers can choose to
downgrade to a CDROM drive.
• D/Bay is optionally available and fully supported across the Latitude D Family line of products
via an integrated D/Bay connector on the D800 and D400 systems and on all Latitude D Family
docking solutions (D/Port, D/View, and D/Dock).
• D/Bay dimensions are 6.2 x 7.2 x 1.0” (156.8 x 183.6 x 26.3 mm). The integrated cable is
non-removable and is 21” in length (54 cm).
• D/Bay weighs 0.56 lb (256 g) when no optical drive is present or 1.05 lbs (477 g) with the
standard 24X CD-ROM.
allow cord
provided
around the
D/Bay exterior
