Specifications 141
18
Specifications
NOTE: Offerings may vary by region. For more information regarding the configuration of your computer,
click Start→ Help and Support and select the option to view information about your computer.
Processor
Processor type Intel
®
Core
™
2 Duo
L1 cache 32 KB per instruction, 32 KB data cache per
core
L2 cache 4 MB
External bus frequency 800 MHz
System Information
System chipset Intel GM965 Express
Data bus width 64 bits
DRAM bus width dual-channel (2) 64-bit buses
Processor address bus width 36 bits
Flash EPROM 2 MB
Graphics bus internal graphics
PCI bus 32 bits
PC Card
CardBus controller O2Micro OZ711EZ1
(PC Cards and 34-mm ExpressCards;
support for USB ExpressCard through
adapter in PC Card slot)
PC Card connector one (supports one Type I or Type II card and
one 34-mm ExpressCard with adapter)
NOTE: You must use an adapter with the
34-mm ExpressCard before you insert the card
into the PC Card connector.
