SYSTEM REQUIREMENT POWER SUPPLY
att or greater power supp
y w
t
att
-p
n
Express® power connector recommended.
SYSTEM REQUIREMENT SPECIAL INSTRUCTIONS
ATI Radeon HD 4870 and ATI Radeon HD 4850 System
Requirements PCI Express® based PC is required with
one X16 lane graphics slot available on the motherboard
450 Watt or greater power supply with 75 Watt 6-pin PCI
Express® power connector recommended (550 Watt and
two 6-pin connectors for dual ATI CrossFireX™) Certified
power supplies are recommended 1GB of system memory
recommended Installation software requires an optical
drive DVD playback requires DVD drive Blu-ray™ / HD
DVD playback requires a Blu-ray / HD DVD drive For a
complete ATI CrossFireX™ system, additional ATI
Radeon™ HD 4800 series graphics card(s), an ATI
CrossFireX Ready motherboard and one ATI CrossFireX
Bridge Interconnect cable per board (included) are
required.
SYSTEM REQUIREMENT HARD DISK 400 MB
SYSTEM REQUIREMENT BUS PCI Express x16
SOLUTION DOUBLE
SYSTEM REQUIREMENT CHASSIS ATX
SYSTEM REQUIREMENT MONITOR
g
ta
at-pane
sp
ays or
-
ompat
e or
digital CRT display or High-resolution VGA monitor
SYSTEM REQUIREMENT INTERNET ACCESS N/A
SYSTEM REQUIREMENT USB N/A
SYSTEM REQUIREMENT CD DVD YES
SYSTEM REQUIREMENT OS WIN2003 YES
SYSTEM REQUIREMENT OS WINXP YES
SYSTEM REQUIREMENT OS WINXP64 YES
SYSTEM REQUIREMENT OS WINVISTA32 YES
SYSTEM REQUIREMENT OS WINVISTA64 YES
PACKAGE INCLUDE ITEM DIAMOND HD 4870 PCIE 512MB GDDR5 VIDEO CARD
PACKAGE INCLUDE ITEM 1 Quick Start Guide
PACKAGE INCLUDE ITEM 2 DVI-TO-VGA ADAPTER
PACKAGE INCLUDE ITEM 3 S-VIDEO CABLE
PACKAGE INCLUDE ITEM 4 CROSSFIRE Brigde Interconnect
PACKAGE INCLUDE ITEM 5 Component HDTV ADAPTER
PACKAGE INCLUDE ITEM 6 INSTALL CD
PACKAGE INCLUDE ITEM 7 Diamond Warranty Card
PACKAGE INCLUDE ITEM 8 DVI-TO-HDMI ADAPTER
OPERATING SYSTEM
4 7/8 X 6/8 X 8 1/4
11.75 X 9.5 X 3
11.75 X 7.25 X 2
2.75 Lbs
3.55 Lbs
PACKAGE INCLUDE
75744800630
757448006384
