Woofer driver
•solid aluminum cone (SC8365: 6-1/2”)
(SC8355: 5-1/4”)
•Aluminum diecast baskets
•Santoprene surround
•Porous flat spider
•Aluminum voice coil former
•Very narrow voice coil gaps
•Vented pole piece
Midrange driver
•1-1/2˝ solid aluminum hard dome
•Neodymium magnet
•Aluminum voice coil former
•Ferro-fluid cooled
•Flush-mounting kit
Tweeter
•3/4˝ solid aluminum hard dome
•Neodymium magnet
•Aluminum voice coil former
•Ferro-fluid cooling
•Flush-mounting kit
Crossover
•Audiophile-grade, speaker-specific matched
component passive crossover with clear lexan cover
•12dB/octave high-pass, 6dB/octave low-pass
Butterworth Optimum Q crossover filters
•OFC wirewound air core inductors and metallized
polypropylene capacitors
•Tweeter protection circuit
•Variable tweeter sensitivity (-3dB/0dB/+3dB)
When size limitations are not a factor for speaker
installations, ECLIPSE Component Series Speakers are an
ideal choice. These are complete two- and three-way
speaker systems with different components and crossovers
designed to synergistically work together in perfect balance
right from the start.
Component Series Speakers
SC8365
6-1/2˝ Component 3-Way Speaker System
• RMS power handling: 100W
• Max. power handling: 300W
• Sensitivity (1Watt/meter) SPL: 88dB
• Crossover frequencies: woofer/midrange 1400Hz,
midrange/tweeter 5kHz
• Mounting Depth: 2-7/8˝
SC8355
5-1/4˝ Component 3-Way Speaker System
• RMS power handling: 85W
• Max. power handling: 250W
• Sensitivity (1Watt/meter) SPL: 87dB
• Crossover frequencies: woofer/midrange 1400Hz,
midrange/tweeter 5kHz
• Mounting Depth: 2-5/8˝
Woofer driver
•Metalized Mica PP
•8-spoke, diecast vented aluminum basket frame
•Santoprene surround
•Symmetrical Low Distortion Spider
•High porous spider material
•1-1/4˝ voice coil
•Aluminum voice coil former
•Narrow gap coil design
•Chromed vented air-cooled pole piece
•Gold-plated input terminals
•Grills included
High Frequency Driver
•Neodymium magnet
•1˝ aluminum hard dome tweeter cone
•Ferro-fluid cooling
•Flush and angle mounting kits included
Crossover
• Passive 2-way optimized component-specific
crossover network
•Compact, low-profile crossover with clear plexiglass
cover
•12dB/octave hi- and low-pass Butterworth filters
•Tweeter protection circuit
•Air/iron core inductors
•ECLIPSE HQ capacitors
•Variable tweeter sensitivity (-3dB/0dB/+3dB)
•Gold-plated input/output terminals
SC8264
6-1/2˝ 2-Way Driver with 1˝ Aluminum Tweeter
• RMS power handling: 85W
• Max. power handling: 250W
• Mounting Depth: 2-7/8˝
SC8254
5-1/4˝ 2-Way Driver with 1˝ Aluminum Tweeter
• RMS power handling: 75W
• Max. power handling: 220W
• Mounting Depth: 2-3/8˝
3-Way SC-Series
2-Way SC-Series
32
