PARTS LIST
INDOOR UNIT
Ref. Part No. Ord. Ref. Part No. Ord.
No MS24Y3F Q'ty No MS24Y3F Q'ty
8-1 Air Filter 67220192 500 Protect Cover 67220242
34 Capacitor (Fan Motor) 67220218 502 SupportStay 67220243
56 Sirocco Fan Assy 67220193 503 LouverShaft 67220244
67 Rubber (Vibration-proof) 67220219 505 LouverStopper 67220004
68 Cap, Plastic 67220220 506 Louver Rod 67220007
69 Louver 67220008 508 Cosmetic Panel-R 67220245
108 Base Assy 67220013 509 Cosmetic Panel-L 67220246
109 Casing, Plastic 67220002 514 Control Box Cover 67220247
124 Kit (Dew Proof Plate) 67220221 520 Flap Base 67230058
126 Motor Fixing Table Assy 67220222 521 LouverLink Cover 67220006
127 Drain Hose Assy 67220015 554 Flap Link-Upper (Step Motor-V) 67220248
138 Kit (Separate Wall-A) 67220215 555 Flap Link-Lower (Step Motor-V) 67220249
146 EvaporatorAssy KB07 67220216 558 Motor Rod-A (Step Motor-V) 67220250
160 Drain Pan Assy (Kit) 67220217 577 Catch TL-119 67220014
164 Fan Motor Assy-IN 67220224 578 Base Bracket (Reinforcement Met
67220251
173 HangerBracket-L 67220228 580 Top Cover 67220001
174 HangerBracket-R 67220225 581 Protector, Metal (Fan Motor) 67220252
184-1 Thermistor Spring-A 67206400 625 Cord Bushing KR-51 67230030
187 Clamp No. 1219 67220226 628 Locking Spacer-B 67207461
195 Clamp SKB-100 67220227 652-1 Thermistor Holder Pipe 67206704
196-1 Clamp SKB-3M 67207409 653-2 Bolt 67220253
223 Control Box 67220229 684 Motor Base 67220254
234 Thermistor Assy-Room 67203510 731 Holder (Guide Rail) 67200566
235 Thermistor Assy-Pipe 67203511 735 Distributor Assy 67220255
236 Controller PCB Assy 67203712 743 Remote Control Unit Holder 67203202
(K01AL-050SHSE-C1)
(K01AL-050SHSE-C1)
755 Casing Cover 67220003
240 Remote Control Unit 37220230 764 Drain Cap 67220256
320 Flap (Upper)-G 67230061 771 Panel 67220257
321 Flap (Lower) 67230062 800 Bypass Pipe Assy 67220258
338 Motor Fixture 67200588
361 Bushing 67210058
361-2 Bushing-B, Plastic 67230060
361-3 Bushing-C, Plastic 67230059
365-1 Special Screw 67220231
365-2 Special Screw 67220232
381 Locking Spacer, KGLS-4S 67207460
385 Indicator PCB Assy 67230056
407 Motor Rod 67220233
408 LouverLink 67220005
416 Insulation (Panel)-A 67220234
417 Insulation (Panel)-B 67220235
418 Insulation (Flap Base) 67220236
439 Drain Pan Wire 67220237
443 Arm Bracket 67220238
470 Separate Wall-B (Kit) 67220239
472 Grille Support 67220240
473 Filter Bracket 67220241
488 Grill-G 67220000
2006.06.13 24
