2-11
R Class System Installation
3. Connect the Console, Web Console, or Graphics Monitor
3. Connect the Console, Web Console, or
Graphics Monitor
1. Console/
Keyboard
If you have an ASCII console (such as the HP 700/96) connect it to the server rear
panel connector labeled Serial 1/ Console. Connect the keyboard to the keyboard
connector at the rear of the console.
2. Web Console A Remote Web Console is shipped with each R Class Server and can be attached to
the inside rear of the server using the two Velcro
strips located there.
To attach the Remote Web Console:
1. Separate the strips to be attached to the web console from the strip already
attached to the side of the chassis.
