HP ProLiant BL460c
Server Blade
Dimensions
Height
2.207 in (5.61 cm)
Depth
20.058 in (50.95c m)
Width
7.154 in (18.17 cm)
Weight
Maximum
14.20 lb (6.44 kg)
Temperature Range
*
Operating
50°F to 95°F (10°C to 35°C)
Non-Operating
-40°F to 140°F (-40°C to 60°C)
Storage
-4°F to 140°F (-20°C to 60°C)
Maximum Wet Bulb
Temperature
86°F (-30°C)
Operating
10% to 90%
Relative Humidity
**
Shipping
10% to 90%
Storage
10% to 95%
*NOTE:
All temperature ratings shown are for sea level. An altitude derating of 1°C per 1.8°F per
1,000 ft (304.8 m) to 10,000 ft (3048 m) is applicable. No direct sunlight allowed. Upper operating
limit is 10,000 ft (3,048 m) or 70 Kpa/10.1 psia. Upper non-operating limit is 30,000 ft (9,144 m) or
30.3 KPa/4.4 psia.
**
NOTE:
Storage maximum humidity of 95% is based on a maximum temperature of 113°F
(45°C). Altitude maximum for storage corresponds to a pressure minimum of 70 KPa.
Smart Array E200i
Controller
Disk Drive and
Enclosure Interface
3G SAS (Serial Attached SCSI)
1.5G SATA (Serial Advanced Technology Attachment)
SAS Connectors
2 internal (SFF8484) x4 wide port connectors
Cache Memory Speed
DDR-1/266 MHz provides up to 4.2 GB/s maximum bandwidth.
Server Interface
x4 2.5G PCIe provides 2GB/s maximum bandwidth.
SAS Speed
x8 3G SAS provides 2.4GB/s maximum bandwidth.
Cache Memory
40-bit 64MB or 128MB cache: ECC protection, battery-backed, and
transportable
Logical Drives
Supported
Up to 32 logical volumes
Maximum Logical Drive
Capacity
144GB (2 x 72GB)
Host Memory
Addressing
64-bit, supporting greater than 2GB server memory space
RAID Support
RAID 5 (Distributed Data Guarding)
RAID 1+0 (Striping & Mirroring)
RAID 0 (Striping)
Upgradeable Firmware
Upgradeable Firmware
QuickSpecs
HP ProLiant BL460c Server Blade
Technical Specifications
DA - 12518 Worldwide QuickSpecs — Version 2 — 6/14/2006
Page 29
