Speaker assembly
Description Spare part number
Speaker assembly (includes cable) 641396-001
Before removing the speaker assembly, remove the following components:
1. Battery (see
Battery on page 43)
2. Service access cover (see
Service access cover on page 44)
3. Hard drive (see
Hard drive on page 45)
4. Optical drive (see
Optical drive on page 47)
5. Keyboard (see
Keyboard on page 52)
6. TouchPad top cover (see
Top cover on page 55)
7. TouchPad LED board (see
TouchPad LED board on page 60)
Remove the speaker assembly:
1. Disconnect the speaker cable (1) from the system board.
2. Gently pry back the tabs on the base enclosure (2) to release the speakers, and then lift up to
remove the speakers (3).
Reverse this procedure to install the speaker assembly.
Component replacement procedures 61
