Illustrated parts catalog 22
Item Description
Assembly part
number
Spare part number
Customer self
repair (on
page 5)
b) Receptacle, door snap, stone* 148525-004 — Optional
2
c) PCI retainer, card guide* 250967-004 — Optional
2
d) Clip, cable, adhesive, 1.77-in* 241347-007 — Optional
2
e) Clip, retainer, 0.125-in diameter* 379046-002 — Optional
2
f) Clip, Torx tool retainer* 373134-001 — Optional
2
29 Hardware kit — 409432-001 —
a) Expansion slot cover* 228072-002 — Optional
2
b) Systems Insight Display tray screws* 192308-009 — Optional
2
c) Standoff, bumper* 252623-001 — Optional
2
d) Screws, SAS cage blank* 192308-002 — Optional
2
30 Rack-mounting kit* 374503-001 377839-001 Optional
2
31
Return kit, tower/rack packing box and
cushions*
— 409434-001 Mandatory
1
Cables
32 Miscellaneous cable kit — 409436-001 Optional
2
a) CD-ROM drive data cable* 108950-041 — —
b) Systems Insight Display cable* 380393-001 — —
c) Fan cage cable* 395575-001 — —
d) Video cable* 392250-001 — —
33 SAS option cable* 361316-006 389952-001 Optional
2
34
Battery cable assembly, 11.5-inch, HP
Smart Array P400 Controller*
408658-001 409124-001 Optional
2
35
Battery cable assembly, 24-inch, HP
Smart Array P400 Controller*
408658-002 409125-001 Optional
2
36 Diskette drive cable* 271946-008 431243-001 Optional
2
37 Second parallel/serial port cable* 384445-002 418300-001 Optional
2
Memory
38 FBDIMMs, registered DDR2 — — —
a) 1-GB, 2x512-MB* 398705-051 416470-001 Optional
2
b) 2-GB, 2x1-GB* 398706-051 416471-001 Optional
2
c) 4-GB, 2x2-GB* 398707-051 416472-001 Optional
2
d) 8-GB, 2x4-GB* 398708-061 416473-001 Optional
2
Options
39 SFF hard drive — — —
a) 36-GB SAS, 10,000-rpm 375859-B21 376596-001 Optional
2
b) 72-GB SAS, 10,000-rpm* 375861-B21 376597-001 Optional
2
