English – 29
MAINTENANCE
Maintenance interval in
hours
Daily main-
tenance
before after
Weekly
3)
main-
tenance
At least
once a
year
Maintenance schedule
The following is a list of the maintenance which should be conducted on the machine. For the items which
are not described in these instructions go to an authorised service workshop.
● = Described in these instructions. ❍ = Not described in these instructions.
25 50 100 300
PageMaintenance
Check for fuel and oil leakage - ❍
Check the parking brake 16+19 ●
Check the engine oil level (when you
refuel) 61 ●●
Check the fuel pump air filter 36 ●
Check the seat safety switch 41 ●
Check the lift lever safety switch 41 ●
Check the parking brake safety switch 41 ●●
Check/clean the engine cooling air intake 39 ●
Check the cutting unit: 53 ●
• blades are secure 53 ●
• condition of blades (sharpness,
shape, etc.) 53 ●
• blade synchronisation (90° between
BioClip) 53 ●
Check steering wires (for play, etc.) 33 ●
Check fasteners (screws, nuts, etc.) - ❍
Start engine and blades, listen for noise - ❍
Clean underside of cutting unit 50 ●
Clean transmission air intake 36 ●●
Check battery acid level 40 ●
Check transmission oil level 63 ●
Check the condition of belts, pulleys, etc. - ❍
Check for damage - ❍
Check tyre pressures (60 kPa) 43 ●
Check for damage to wire guide at
articulated joint - ❍
Clean the area around the engine
thoroughly 39 ●
Clean carefully around the muffler 39 ●
Clean thoroughly around transmission 36 ●
Clean all belts, pulleys, etc. 57 ●
Lubricate belt tensioner (nipple) 60 ●
Lubricate triangle link 59 ●
Lubricate the driver’s seat 59 ●
Lubricate all wires 57 ●
Lubricate bearing surfaces on cutting unit 57 ●
Clean inside frame tunnel - ❍
Lubricate pedal mechanism inside frame
tunnel 58 ●
Lubricate the gear lever 62 ●
Lubricate the parking brake wire 63 ●
Lubricate throttle control 60 ●
