110
Zone 2—Continued
To use Zone 2, you must make this setting. It enables the
speakers connected to the ZONE 2 SPEAKERS termi-
nals so that they produce sound when Zone 2 is used.
Note:
This procedure can also be performed on the AV receiver
by using its [Setup] button, arrow buttons, and [Enter]
button.
Setting the Powered Zone 2
1
Press the [Receiver] button fol-
lowed by the [Setup] button.
The main menu appears onscreen.
2
Use the Up and Down [ ]/[ ]
buttons to select “7. Hardware
Setup,” and then press [Enter].
The Hardware Setup menu appears.
3
Use the Up and Down [ ]/[ ]
buttons to select “2. Zone2,” and
then press [Enter].
The Zone2 menu appears.
4
Use the Up and Down [ ]/[ ]
buttons to select “Powered
Zone2,” and use the Left and
Right [ ]/[ ] buttons to select:
Not Act: ZONE 2 SPEAKERS termi-
nals deactivated.
Act: ZONE 2 SPEAKERS termi-
nals activated.
When Zone 2 is activated and turned on
(see page 112), the speakers connected
to the ZONE 2 SPEAKERS terminals
output sound, but the speakers con-
nected to the SURR BACK SPEAK-
ERS terminals do not (when Zone 2 is
activated but not used, the surround
back speakers work as normal).
7. Hardware Setup
1. Remote Control
2. Zone2
3. Tuner
4. Analog Multich
5. HDMI
6. Network
7–2. Zone2
Powered Zone2 Not Act
Zone2 Out Fixed
5
Press the [Setup] button.
The setup menu closes.
