26
Model
Item AV-24WT2EK AV-28WT2EK
TV RF systems CCIR I
Colour systems PAL (NTSC 3.58 / 4.43 MHz only in EXT modes)
Channels and frequencies E21-E69
Sound-multiplex systems NICAM system
Teletext systems Fastext (United Kingdom system) / WST (standard system)
Power requirements AC 220 – 240 V, 50 Hz
Power consumption Maximum 136 W, Maximum 140 W,
Average 111 W, Standby 1.5 W Average 121 W, Standby 1.5 W
Picture tube size Visible area 56 cm Visible area 66 cm
(measured diagonally) (measured diagonally)
Audio output Rated Power output 5 W + 5 W
Speakers 3 × 10 cm oval × 2 10 cm round × 2
External input / output EXT-1, EXT-2 21-pin Euroconnector (SCART)
EXT-3 VIDEO IN (RCA)
AUDIO L / R IN (RCA)
Headphone jack (stereo mini jack, dia. 3.5 mm)
Dimensions (W × H × D) 645 mm × 427 mm × 443 mm 716 mm × 489 mm × 496 mm
Weight 23.0 kg 32.9 kg
Accessories Remote control unit RM-C794 × 1
AAA (R03) dry cell battery × 2
SPECIFICATIONS
Design and specifications subject to change without notice.
Pictures displayed on the screen using this TV’s image-processing functions should not be shown for any
commercial or demonstration purpose in public places (tearooms and halls in hotels, etc.) without the consent of
the owners of copyright of the original picture sources, as this constitutes an infringement of copyright.
