EN 61
5
SUPPLY POWER
Plug the AC Charger Station’s power cord into
an AC outlet.
6
TURN ON POWER
Turn the camcorder’s Power Dial to “PLAY”,
“
” or “
M
” while pressing down the lock
button located on the dial and turn on the
other units.
NOTES:
●
You cannot use the battery pack installed in the
camcorder as the power supply since a digital
signal is output from the DV OUT/IN connector
only when using the AC Charger Station.
●
For Digital Dubbing, this camcorder can be
connected only to one device at a time. This
camcorder can also be used as a recorder
(
੬
pg. 63).
●
Also refer to the instruction manuals of the
connected units.
1
CONFIRM POWER-OFF STATUS
Make sure all the units are turned off.
2
ATTACH CAMCORDER TO AC
CHARGER STATION
Attach the camcorder to the AC Charger
Station referring to step 2 as shown in the
illustration on pg. 58.
3
CONNECT CAMCORDER TO PRINTER
OR VIDEO UNIT EQUIPPED WITH
DV INPUT CONNECTOR
Pull out the connector cover and open it. Make
connections to the device you want to connect
to using the DV cable, as shown in the
illustration.
4
CONNECT PRINTER TO PC
Connect the printer cable to the printer’s
PARALLEL connector and the PC’s PARALLEL
(PRINTER) connector.
