Parameter List
EDIT SELECT 1/2
Type 1 2 3 4 5
VOICE
SYNTH/VOCODER
SYNTH/VOCODER SINGLE/LAYER VOICE ASSIGN TRIGGER MODE UNISON DETUNE
(➝p.16)
Synthesizer, Vocoder Single, Layer Mono, Poly, Unison Single, Multi 0...99
PITCH
SYNTH/VOCODER
TRANSPOSE TUNE PORTAMENTO BEND RANGE VIBRATO INT
(➝p.17)
-24...24 -50...50 0...127 -12...12 -63...63
OSC1
SYNTH/VOCODER
WAVE CONTROL 1 CONTROL 2 — —
(➝p.18)
Saw, Square, Triangle, Sine, Vox, 0...127 0...127 — —
DWGS — 1...64 — —
Noise, Audio In 0...127 0...127 — —
OSC2
SYNTH
WAVE OSC MOD SEMITONE TUNE —
(➝p.22)
Saw, Square, Triangle OFF, Ring, Sync, RingSync -24...24 -63...63 —
AUDIO IN 1
VOCODER
GATE SENSE THRESHOLD HPF LEVEL HPF GATE —
(➝p.33)
0...127 0...127 0...127 Disable, Enable —
MIXER
SYNTH
OSC 1 LEVEL OSC 2 LEVEL NOISE LEVEL — —
(➝p.23)
0...127 0...127 0...127 — —
MIXER VOCODER OSC 1 LEVEL INST LEVEL NOISE LEVEL — —
(➝p.34)
0...127 0...127 0...127 — —
FILTER
SYNTH
TYPE CUTOFF RESONANCE FILTER EG INT FILTER KEY TRACK
(➝p.24)
-24dB LPF, -12dB LPF, -12dB BPF, -12dB HPF 0...127 0...127 -63...63 -63...63
FILTER
VOCODER
FORMANT SHIFT CUTOFF RESONANCE E.F.SENSE —
(➝p.35)
0, 1, 2, -1, -2 -63...63 0...127 0...126, Hold —
FILTER EG
SYNTH
ATTACK DECAY SUSTAIN RELEASE EG RESET
(➝p.26)
0...127 0...127 0...127 0...127 OFF, ON
FC MOD
VOCODER
SOURCE INTENSITY — — —
(➝p.36)
AMP EG, LFO 1, LFO 2, Velocity, KBD Track, -63...63 — — —
Pitch Bend, MOD.Wheel
AMP
SYNTH
LEVEL PANPOT DISTORTION KBD TRACK —
(➝p.27)
0...127 L63...Center...R63 OFF, ON -63...63 —
AMP
VOCODER
LEVEL DIRECT LEVEL DISTORTION KBD TRACK —
(➝p.37)
0...127 0...127 OFF, ON -63...63 —
AMP EG
SYNTH/VOCODER
ATTACK DECAY SUSTAIN RELEASE EG RESET
(➝p.28)
0...127 0...127 0...127 0...127 OFF, ON
LFO 1
SYNTH/VOCODER
WAVE KEY SYNC TEMPO SYNC FREQUENCY/SYNC NOTE —
(➝p.29)
Saw, Square1, Triangle, Sample&Hold OFF, Timbre, Voice OFF, ON 0...127/1.1...1.32 —
LFO 2
SYNTH/VOCODER
WAVE KEY SYNC TEMPO SYNC FREQUENCY/SYNC NOTE —
(➝p.29)
Saw, Square2, Sine, Sample&Hold OFF, Timbre, Voice OFF, ON 0...127/1.1...1.32 —
PATCH 1, 2, 3, 4 SYNTH
SOURCE DEST MOD INT — —
(➝p.30)
FILTER EG, AMP EG, LFO 1, LFO 2, Pitch, OSC2 Tune, OSC1 Control1, Noise -63...63 — —
Velocity, KBD Track, Pitch Bend, MOD.Wheel
Level, CutOff, Amp, Pan, LFO2 Frequency
CH LEVEL A
VOCODER
CH 1 LEVEL CH 2 LEVEL CH 3 LEVEL CH 4 LEVEL —
(➝p.38)
0...127 0...127 0...127 0...127 —
CH LEVEL B
VOCODER
CH 5 LEVEL CH 6 LEVEL CH 7 LEVEL CH 8 LEVEL —
(➝p.38)
0...127 0...127 0...127 0...127 —
CH PAN A
VOCODER
CH 1 PAN CH 2 PAN CH 3 PAN CH 4 PAN —
(➝p.38)
L63...Center...R63 L63...Center...R63 L63...Center...R63 L63...Center...R63 —
CH PAN B
VOCODER
CH 5 PAN CH 6 PAN CH 7 PAN CH 8 PAN —
(➝p.38)
L63...Center...R63 L63...Center...R63 L63...Center...R63 L63...Center...R63 —
MOD FX
SYNTH/VOCODER
TYPE LFO SPEED EFFECT DEPTH — —
(➝p.40)
Chorus/Flanger, Ensemble, Phaser 0...127 0...127 — —
DELAY
SYNTH/VOCODER
TYPE TEMPO SYNC DELAY TIME/SYNC NOTE DELAY DEPTH —
(➝p.41)
Stereo Delay, Cross Delay, L/R Delay OFF, ON 0...127/1.32...1.1 0...127 —
EQ
SYNTH/VOCODER
LOW EQ FREQ. LOW EQ GAIN HI EQ FREQ. HI EQ GAIN —
(➝p.42)
40...1.00 -12...12 1.00...18.0 -12...12 —
ARPEG. A
SYNTH/VOCODER
TEMPO RESOLUTION GATE TYPE RANGE
(➝p.44)
20...300 1/24...1/4 0...100 Up, Down, Alternate 1, Alternate 2, 1...4
Random, Trigger
ARPEG. B
SYNTH/VOCODER
LATCH SWING KEY SYNC LAST STEP TARGET TIMBRE
(➝p.45)
OFF, ON -100...100 OFF, ON 1...8 Both, Timbre 1, Timbre 2
GLOBAL
GLOBAL
MASTER TUNE MASTER TRANSPOSE VELOCITY CURVE POSITION AUDIO IN THRU
(➝p.47)
30.0...50.0 -12...12 Curve, 1...127 Post KBD, Pre TG OFF, ON
MIDI
MIDI
MIDI CH LOCAL CLOCK — —
(➝p.51)
1...16 OFF, ON Internal, External, Auto — —
