1040 DIMM
For access, remove these FRUs in order:
v “1010 Battery pack” on page 83
v “1020 Optical drive or second battery or travel cover” on page 84
Table 12. Removal steps of DIMM
Note: Loosen the screws 1, but do not remove them.
1
2
Removing and replacing a FRU 87
